ENGINE
2.32
Assembly, Cont.
39. Apply Loctitet 262 evenly to the flywheel mounting
taper on crankshaft. Install woodruff key.
40. Install flywheel. Apply Loctitet 242 to crankshaft
threads. Install washer and nut.
41. Use flywheel holder to hold flywheel and torque nut
to specification found in beginning of this chapter.
42. Install recoil hub and recoil housing. Torque bolts to
specification.
43. Install engine in chassis and align clutches.
44. Refer to General Inspection Procedures in this
chapter to fill and bleed cooling system and oil
pump.
Flywheel Holder:
PN 8700229
Recoil Hub and Housing Bolt
Torque:
108 in. lbs. (12.5 Nm)
