Fig. 39: Details of the volume channel
Main group Subgroup Function
I: Alarm notifications
1 Technical alarm
2 Measured value too low
3 Measured value too high
4 Disabled setting
5 The feed chemical storage tank is empty.
II: Measured value and units
6 Measured value lower than can be displayed on the scale.
7 Measured value higher than can be displayed on the scale.
8 Measured value cannot be displayed.
9 Measured value cannot be measured. Technical alarm
III: Metering status and capacity
Details of the volume channel
Operating concept and operation
38
