VessRAID 1740s, 1840s Product Manual
94
• Operational Status – OK is normal. Can also show Rebuilding, Forced
Online, Forced Offline, Transition Running, PDM Running, Media Patrol
Running, Stale, PFA, Offline, or Dead.
• Configuration Status – The array to which the drive is assigned or its spare
designation, including Unconfigured, Stale, PFA, Global Spare, Dedicated
Spare, Revertible Global Spare, Revertible Dedicated Spare.
Adjustable Items
• Write Cache
• Read Look Ahead Cache
• Read Cache (SAS drive only)
• Command Queuing
• DMA Mode (SATA drives only)
See “Making Global Physical Drive Settings” on page 93.
Viewing Physical Drive Statistics
To view physical drive statistics:
1. Click the Subsystem icon in Tree View.
2. Click the Enclosures icon.
3. Click the Enclosure icon.
4. Click the Physical Drives icon.
5. Click a Physical Drive icon.
6. From the dropdown menu on the Information tab, choose Statistics.
Clearing Statistics
To clear statistics, see “Clearing Statistics” on page 79.
Making Physical Drive Settings
An alias is the only setting you can make to an individual physical drive. All other
settings are global. See “Making Global Physical Drive Settings” on page 93.
To make physical drive settings:
1. Click the Subsystem icon in Tree View.
2. Click the Enclosures icon.
3. Click the Enclosure icon.
4. Click the Physical Drives icon.
5. Click a Physical Drive icon.
