ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Operation
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 111 of 196
Source Net Address
Byte[6]
The network address of the source (optional).
Source MAC Address
Byte[]
The MAC address of the source (optional).
Destination API
Byte
The application process instance of the destination.
Destination SCL
Byte
The access level of the destination (0 = no access level used).
Destination Net Address
Byte[6]
The network address of the destination (optional).
Destination MAC Address
Byte[]
The MAC address of the destination (optional).
Response Data:
Table 5.13 – DPV1 Class 2 Initialize Response
Parameter
Data
Type
Description
Status
Byte
This is the status of the DPV1 data exchange. See appendix
for the definitions of the returned status.
Extended Status
Byte[3]
This is the extended status of the DPV1 data exchange. See
appendix for the definitions of the returned extended status.
Send Timeout
Short
Timeout time for Class 2 connection in ms.
Features Supported
Short
Refer to the PROFIBUS – DP Extensions to EN 50170 (DPV1)
for information regarding these parameters.
Profile Features
Supported
Short
Profile Ident Number
Short
Connection Reference
Byte
The connection reference is a reference number that must be
used for further communication on this connection (e.g. Read,
Write, or Abort).
DPV1 Class 2 Abort
CIP Message:
Table 5.14 – DPV1 Class 2 Abort Message
Parameter
Description
Service Code
0x4E (Hex)
Class
0x432 (Hex)
Instance
1
Attribute
N/A
Request Data Length
7
Request Data:
Table 5.15 – DPV1 Class 2 Abort Request
Parameter
Data Type
Description
Reserved
Long
-
Connection Reference
Byte
Connection Reference Received from the DPV1 Class 2
Initialize Response.
Subnet
Byte
Location of the source of the abort request. (0 = NO, 1 =
SUBNET-LOCAL, 2 = SUBNET-REMOTE, 3-255 =
Reserved)
Instance Reason Code
Byte
The Instance indicates the protocol instance that detected a
problem in the abort request (FDL, MSAC_C2, USER). The
Reason Code indicates the reason for the abort request.
Refer to the PROFIBUS – DP Extensions to EN 50170
(DPV1) for more information regarding this parameter.
Response Data:
Table 5.16 – DPV1 Class 2 Abort Response
Parameter
Data Type
Description
None
-
-
