PLX51-PBM Operation
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 112 of 196
DPV1 Class 2 Read
CIP Message:
Table 5.17 – DPV1 Class 2 Read Message
Request Data:
Table 5.18 – DPV1 Class 2 Read Request
The amount of time (in milliseconds) the PLX51-PBM waits
for a DPV1 response before timing out and responding to
the EtherNet/IP request with a Timeout Status.
Connection Reference Received from the DPV1 Class 2
Initialize Response.
The DPV1 Slot number which must be read.
The DPV1 Index number which must be read.
The maximum number of bytes that must be read.
Response Data:
Table 5.19 – DPV1 Class 2 Read Response
This is the status of the DPV1 data exchange. See appendix
for the definitions of the returned status.
This is the extended status of the DPV1 data exchange. See
appendix for the definitions of the returned extended status.
The length of the data returned.
The data from the DPV1 Read request. The number of bytes
will be equal to the Data Length in the response.
