ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Operation
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 116 of 196
Global Control
Global control commands are multi-cast PROFIBUS commands which can be sent to
a group of slave devices.
CIP Message
Below are the EtherNet/IP CIP message parameters as well as the request and
response data structures.
Table 5.29 – Global Control Message
Parameter
Description
Service Code
0x54 (Hex)
Class
0x432 (Hex)
Instance
1
Attribute
N/A
Request Data Length
6
Request Data:
Table 5.30 – Global Control Request
Parameter
Data Type
Description
Timeout
Long
The amount of time (in milliseconds) the PLX51-PBM waits for
a response before timing out and responding to the EtherNet/IP
request with a Timeout Status.
Control
Byte
The Global Control action:
0 - Release the Clear mode for the devices
2 - Force the Clear Mode of devices
4 - Freeze
8 - UnFreeze
12 - UnFreeze
+ 16 - Sync
+ 32 – UnSync
+ 48 - UnSync
Group
Byte
The destination Group.
Response Data:
Table 5.31 – Global Control Response
Parameter
Data Type
Description
Status
Byte
This is the status of the Global Control transmission:
0x00 – Success
0x13 – Failed
