ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Migrating Legacy PCB Projects
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 146 of 196
The PROFIBUS Master window will open. Select the Export Master Config button
located at the bottom of the window.
If the Export Master Config button is disabled, then first select the Configure
PROFIBUS button. This will open the PROFIBUS configuration tool, once this tool
has been closed the Export Master Config button will then be enabled.
Figure 6.3 – PCB Export Master Configuration
The generated export (XML) file can then be saved.
Figure 6.4 – PCB – Save Export XML File
