ProSoft Technology PLX51-PBM

PLX51-PBM Diagnostics
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 175 of 196
Table 8.8 - Device Status Monitoring – General Tab
Parameter
Description
Node Address
The selected slave device station address
Instance Name
The configured instance name of the device
Vendor
The device Vendor name
Model
The device Model name
Identity
The device PNO identity
Revision
The device revision
Device Status
The current status of the device:
Online
The slave device is online.
Data Exchange Active
The slave device is exchanging DPV0 process data with the
PLX51-PBM.
Disabled (PLC)
The slave device has been disabled from DPV0 data exchange
from the Logix controller using the PLX51-PBM output assembly.
Identity Mismatch
The device configured in the PLX50 Configuration Utility and the
device online at the specific station address do not match.
StationID Mismatch (PLC)
The station address entered from the Logix controller using the
PLX51-PBM output assembly does not match the station
address of the configured slave device.
CRC Mismatch (PLC)
Indicates the mapping from the Logix controller does not match
the configured mapping.
Error
Device Error flag
Alarm Pending
An alarm is pending in the specific slave device.
Diagnostics Pending
There is new diagnostics pending in the slave device.
