ProSoft Technology PLX51-PBM User Manual

PLX51-PBM Diagnostics
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 177 of 196
Table 8.9 - Device Status Monitoring – Statistics Tab
Parameter
Description
Tx Packet Count
The number of PROFIBUS packets transmitted.
Rx Packet Count
The number of PROFIBUS packets received.
Checksum Failed Packet Count
The number of PROFIBUS packets that had a failed checksum.
No Reply Count
The number of PROFIBUS requests from the PLX51-PBM (or
DP Master if in Slave Mode) where the station did not respond.
DPV1 Class 1 Read Tx Count
The number of PROFIBUS DPV1 Class 1 Read requests sent
from the PLX51-PBM to the specific device.
PLX51-PBM Slave mode: The number of DPV1 Class 1 Read
responses sent by the specific device.
DPV1 Class 1 Read Rx Count
The number of successful PROFIBUS DPV1 Class 1 Read
responses received from the specific device.
PLX51-PBM Slave mode: The number of DPV1 Class 1 Read
requests received by the specific device.
DPV1 Class 1 Read Err Count
The number of failed PROFIBUS DPV1 Class 1 Read responses
received from the specific device.
(N/A for PLX51-PBM Slave mode)
DPV1 Class 1 Write Tx Count
The number of PROFIBUS DPV1 Class 1 Write requests sent
from the PLX51-PBM to the specific device.
PLX51-PBM Slave mode: The number of DPV1 Class 1 Write
responses sent by the specific device.
DPV1 Class 1 Write Rx Count
The number of successful PROFIBUS DPV1 Class 1 Write
responses received from the specific device.
PLX51-PBM Slave mode: The number of DPV1 Class 1 Write
requests received by the specific device.
DPV1 Class 1 Write Err Count
The number of failed PROFIBUS DPV1 Class 1 Write responses
received from the specific device.
(N/A for PLX51-PBM Slave mode)
DPV1 Class 2 Init Tx Count
(PLX51-PBM Master mode only) The number of PROFIBUS
DPV1 Class 2 Initialize requests sent from the PLX51-PBM to
the specific device.
DPV1 Class 2 Init Rx Count
(PLX51-PBM Master mode only) The number of successful
PROFIBUS DPV1 Class 2 Initialize responses received from the
specific device.
DPV1 Class 2 Init Err Count
(PLX51-PBM Master mode only) The number of failed
PROFIBUS DPV1 Class 2 Initialize responses received from the
specific device.
DPV1 Class 2 Abort Tx Count
(PLX51-PBM Master mode only) The number of PROFIBUS
DPV1 Class 2 Abort requests sent from the PLX51-PBM to the
specific device.
DPV1 Class 2 Abort Rx Count
(PLX51-PBM Master mode only) The number of PROFIBUS
DPV1 Class 2 Abort messages received from the specific
device.
DPV1 Class 2 Read Tx Count
(PLX51-PBM Master mode only) The number of PROFIBUS
DPV1 Class 2 Read requests sent from the PLX51-PBM to the
specific device.
DPV1 Class 2 Read Rx Count
(PLX51-PBM Master mode only) The number of successful
PROFIBUS DPV1 Class 2 Read responses received from the
specific device.
DPV1 Class 2 Read Err Count
(PLX51-PBM Master mode only) The number of failed
PROFIBUS DPV1 Class 2 Read responses received from the
specific device.
DPV1 Class 2 Write Tx Count
(PLX51-PBM Master mode only) The number of PROFIBUS
DPV1 Class 2 Write requests sent from the PLX51-PBM to the
specific device.
