Pulsar ULTRA TWIN User Manual

Page 105
P1-101, P2-101 Transducer
This parameter should be set to the transducer being used with the unit, and
can be set to one of the following:
Option
Description
When P100 = 1 (Distance), 2 (Level), 3 (Space) or 6 (Volume)
0=Auxiliary
(Optional)
Use the optional mA input (Please consult Pulsar
for availability).
1 = dB3
Transducer is a dB3. Range 0.410 to 9.843 feet
2 = dB6 (Default)
Transducer is a dB6. Range 0.984 to 19.685 feet
3= dB10
Transducer is a dB10. Range 0.984 to 32.808 feet
4= dB15
Transducer is a dB15. Range 1.640 to 49.213 feet
5= dB25
Transducer is a dB25. Range 1.969 to 82.021 feet
6 = dB40
Transducer is a dB40. Range 3.937 to 131.234 feet
7 = dBS6
Transducer is a dBS6. Range 0.656 to 19.685 feet
8 = dBMach3
Transducer is a dBMach3 Range 0.0 to 7.956 feet
When P100 = 4 (OCM Head) or 5 (OCM Flow)
1 = dBMach3
(Default)
Transducer is a dBMach3 Range 0.0 to 7.956 feet
2 = dB6
Transducer is a dB6. Range 0.984 to 19.685
3= dB10
Transducer is a dB10. Range 0.984 to 32.808 feet
4= dB15
Transducer is a dB15. Range 1.640 to 49.213 feet
7 = dBS6
Transducer is a dBS6. Range 0.656 to 19.685 feet
Important Information
The choices of transducers available will be dependent on the Mode,
(P1-100, P2-100), selected and will vary from application to application.
P1-102, P2-102 Material
This parameter should be set to the type of material being monitored.
Option
Description
1 = Liquid (Default)
Use for liquids and flat solid materials
2 = Solid
Solid material that is heaped or at an angle
