Page 174
Operation
P1 and P2
P*891 mA2 Mode
This parameter determines how the ma Output relates to what is measured.
By default it will be representative of the selected Mode (P2-100), but it
can be set to operate as follows:
P2-100 = 1 (Distance), 2 (Level) or 3 (Space)
Option
Description
0 = Default
mA output relative to Mode P1-100
1 = Distance
mA output relative to distance.
2 = Level
mA output relative to level.
3 = Space
mA output is relative to space.
P2-100 = 4 (OCM Head) or 5 (OCM Flow)
Option
Description
0 = Default
mA output relative to Mode P1-100
1 = Distance
mA output relative to distance.
2 = Level
mA output relative to level.
3 = Space
mA output is relative to space.
4 = OCM Head
mA output is relative to OCM Head
5 = OCM Flow
mA output is relative to OCM Fow
P2-100 = 6 (Volume)
Option
Description
0 = Default
mA output relative to Mode P1-100
1 = Distance
mA output relative to distance.
2 = Level
mA output relative to level.
3 = Space
mA output is relative to space.
6 = Volume
mA output is relative to volume
