Page #186 background imageLoading...
Page #186 background image
Page 178
Compensation Parameters
Offset
P1 or P2
P1-851, P2-851 Measurement Offset
The value of this parameter is added to the measured distance, in
Measurement Units (P*104).
This Offset will be added to the level, as derived from the transducer, and
will affect everything including the reading on the display, the relay
setpoints and the mA output(s) allocated to the relevant point.
Temperature
P1 or P2
P1-852, P2-825 Temperature Source
This parameter determines the source of the temperature measurement. By
default it is set to automatic (P1-852, P2-852=1), which will automatically
detect if a temperature sensor is available from the transducer(s). If for any
reason, no temperature input is received, then the Fixed Temp value is used,
as set by P1-854, P2-854.
The temperature source can be specifically set as follows:
Option
Description
1 = Automatic (Default)
Will automatically select transducer
temperature sensor, if available, or fixed
temperature (P1-854, P2-854) if no
temperature sensor found.
2 = Xducer
Always uses temperature reading from
transducer.
3 = Fixed
Always uses fixed temperature (P1-854,
P2-854)
4 = Ext Range “A”
Uses an optional external temperature
sensor with an operating range of -25
o
C to
50
o
C.
5 = Ext Range “B”
Uses an optional external temperature
sensor with an operating range of -25
o
C to
125
o
C.
