Pulsar ULTRA TWIN User Manual

Page 167
P1-824, P2-824 Totaliser Allocation
This parameter determines which point(s) of measurement the totaliser(s)
will react to.
Option
Description
0 = Off (Default)
Totaliser will be disabled
1 = Point 1 (P1-824)
Totaliser 1 allocated to Point 1
2 = Point 2 (P2-824)
Totaliser 2 allocated to Point 2
3= Avg. 1 & 2
Totaliser allocated to Average flow of Point 1
& 2 will be totalisied.
4= Sum 1 + 2
Totaliser allocated to Sum flow of Point 1 + 2
will be totalisied
Important Information
When the totaliser is to be used to totalise the average or sum of two points of
flow measurement, then both points must be set to the same units of
measurement i.e. P1-100 and P2-100 are set for 4 (OCM Head) or 5 (OCM
Flow), then P1-706, P2-706 (Volume Units) & P1-707, P2-707 (Time Units)
must be the same, also the totalisers must have the same multiplication factor
applied, P1-823, P2-823 (Total.Multi).
Bargraph
P1 or P2
P1-829, P2-829 Bargraph
By default the bargraph will be representative of the level being measured,
as a percentage of the Span P1-106, P2-106. This parameter is
automatically set to the correct default option when selecting the Mode P1-
100, P2-100 but can be changed if required.
The options, dependant on the value entered for Mode P1-100, P2-100 are
as follows:
P1-100, P2-100 = 1 (Distance), 2 (Level) or 3 (Space)
Option
Description
2 = Level (Default)
Bargraph will be representative of level.
