Page 166
P1-820, P2-820 Totaliser 1&2
Displays the current value of the non-resettable totaliser(s). During run
mode these totalisers can be viewed via the “Totaliser” hot key . Unlike
the resettable totaliser these totalisers cannot be reset whilst in run mode, it
can however be reset whilst in program mode by accessing P1-820
Totaliser 1, P2-820 Totaliser 2 and entering zero.
P1-821, P2-821 Totaliser ( R )1&2
Displays the current value of the resettable totaliser(s), these totalisers can
be allocated to appear, during run mode, on the auxiliary display line (P1-
816, P2-816) or alternatively accessed via the “Totaliser” hot key .
P1-822, P2-822 Totaliser Decimal Places
This parameter determines the number of decimal places in the totaliser(s)
during run mode. It can be set between 1 and 3. Default = 2
P1-823, P2-823 Totaliser Multiplication Factor
Use this parameter if the totaliser increments by to large or small amount,
enter the factor by which the actual flow rate is multiplied by before
incrementing the totaliser .
E.g. if volume is being calculated and displayed in ltrs and it is desired to
increment the totaliser in cubic metres select 7 = *1000.
When viewing, the totaliser display will state, “Units are: L*1000”, and the
totaliser will be incremented every 1000 litres
Options are:
Option
Description
1= 1/1000
Totaliser will increment every 1/1000
th
units of volume
2= 1/100
Totaliser will increment every 1/100
th
units of volume
3= 1/10
Totaliser will increment every 1/10
th
units of volume
4= 1 (Default)
Totaliser will increment every 1 units of volume
5= 10
Totaliser will increment every 10 units of volume
6= 100
Totaliser will increment every 100 units of volume
7= 1,000
Totaliser will increment every 1000 units of volume
8= 10,000
Totaliser will increment every 10,000 units of volume
9= 100,000
Totaliser will increment every 100,000 units of volume
10= 1,000,000
Totaliser will increment every 1,000,000 units of
volume
