Page 4
Product Specification
Physical
Wall Mount
Overall Outside dimensions 9.25 x 7.24 x 4.72 inch
(235 x 184 x 120 mm)
Weight Nominal 2.2lbs (1 kg)
Enclosure material/description Polycarbonate, flame resistant to
UL94-5V
Cable entry detail 10 cable entry knock outs, 5 x M20,
1 x M16 underside
4 x PG11 at rear
Fascia Mount
Outside dimensions 7.87 x 4.41 x 4.25 inch
(200 x 112 x 108 mm)
Weight Nominal 2.8lbs (1.3kg)
Enclosure material/description Stainless Steel back, Polycarbonate
UL94-V0 front and bezel
Transducer cable extensions 3-conductor 20AWG screened
Maximum separation 3,280 ft (1000 metres)
Environmental
Mounting - Wall Mount Indoor/Outdoor
- Fascia Mount Indoor
Relative Humidity (IP Rating)
- Wall Mount IP65 (NEMA 4X) when closed IP20
when open
- Fascia Mount (IP64 from front of panel) <35
o
C
(95
o
F) at 93% relative humidity
Pollution Degree 2
Altitude 2000m maximum
Max. & min. temperature (electronics) -4
o
F to 120
o
F (-20 ºC to +50 ºC)
Flammable atmosphere approval Safe area: compatible with approved
dB transducers (see transducer spec'
sheet)
Approvals
UL Certificate Number E257330
CE approval See EC Declaration of Conformity
Performance
Accuracy 0.25% of the measured range or
0.24" (6 mm) (whichever is greater)
Resolution 0.1% of the measured range or 0.08"
(2 mm) (whichever is greater)
Max. range Dependant on application and
transducer (maximum 131ft (40m)
dB40)
Min. range Dependent upon application and
transducer (minimum zero dB Mach3)
Rate response fully adjustable
