Pulsar ULTRA TWIN User Manual

Page 109
P*210, P*220, P*230, P*240, P*250, P*260 - Relay Type
This parameter defines what type each relay should be, see the table below
for available options, which will be dependent on the Operational Mode
(P100), selected.
Option
Description
0= Not In Use (Default)
Relay not in use or programmed and LED
will always be off.
1= Alarm
Relay is programmed as an alarm relay,
which will de-energise ON, and energise
OFF. This will ensure an alarm is raised if
the power fails to the unit.
2= Pump
Relay is programmed as a pump relay, which
will energise ON, and de-energise OFF.
3= Control
Relay is programmed as a control relay,
which will energise ON, and de-energise
OFF.
4= Miscellaneous
Relay is programmed as a miscellaneous
relay, which will energise ON, and de-
energise OFF.
Alarms
P1 and P2
When P*210, 220, 230, 240, 250, 260 =1 (Alarm)
The second parameter for each relay determines the function of the alarm.
P*211, P*221, P*231, P*241, P*251, P*261 - Relay Function
This parameter defines what function the alarm will respond to as follows.
Option
Description
0= Off (Default)
Relay will not operate.
1= Level
Alarm is based on the level in the vessel, and the
type of level alarm (P*212, 222, 232, 242, 252,
262) and two setpoints must be set (P*213, 223,
233, 243, 253, 263 & P*214, 224, 234, 244, 254,
264). Setpoints are entered in Display Units or %
of span as referenced to Empty Level.
