Page #184 background imageLoading...
Page #184 background image
Page 176
Trim
P1 and P2
P*896 mA2 Low Trim
If the remote device you are connected to is not calibrated, and not showing
the correct low value (reading), then you can trim it using this parameter.
You can either type in the offset directly, or use the arrow keys to move the
output up and down until you get the expected result (reading) on the remote
device that is connected.
P*897 mA2 High Trim
If the remote device you are connected to is not calibrated, and not showing
the correct high value (reading), then you can trim it using this parameter.
You can either type in the offset directly, or use the arrow keys to move the
output up and down until you get the expected result (reading) on the remote
device that is connected.
Failsafe
P1 and P2
P*898 mA2 Fail-safe Mode
This parameter determines what happens to mA output 2 in the event of the
unit going into fail-safe mode. The default is to do the same as the system
fail-safe (P2-808), but this can be overridden to force the mA output to an
independent fail-safe mode as follows:
Option
Description
0 = Default
mA output will fail as per P2-808.
1 = Hold
mA output will retain its last known value.
2 = Low
mA output will fail to its low condition.
3 = High
mA output will fail to its high condition.
