Page 38
There are three categories of application, which are all described later in this
chapter. They are level/volume, pump or flow all with the choice of control
functions and alarms.
Level or Volume
If you want to set-up a level or volume application, as described in the
following examples, then choose 1 for Level/Vol. You will then be given a
choice of 1 = Level or 2 = Volume.
Choose Your Application
If you want to set-up a basic level monitoring application, as described in
the following example 1, then choose 1 for Level/Vol. and then 1 for level.
If you want to set-up a level monitoring application with control relays, as
described in the following example 2, then choose 1 for Level/Vol.
followed by 1 for level and choose either control down (press 1) or control
up (press 2).
If you want to set-up a volume application, as described in the following
example 3, then choose 1 for Level/Vol. followed by 2 for volume, you
then need to decide if any control function is required and choose the
appropriate option no control (press 0), control down (press 1) or control
up (press 2).
Once you have chosen your application you will be asked a series of
questions which are answered by choosing the appropriate option as detailed
in the flow chart below. Once all of the questions have been answered you
will be prompted to provide further information, as detailed in the tables
below, in order to complete the programming of the unit.
