Setpoint
P1 and P2
By default the mA Output will represent the empty (0 or 4mA) dependant
on P*890 (mA Range) and 100% of the operational span (20mA), but you
may wish to have the output represent a section of the operational span. For
example, the application has an operational span of 20 feet but output is to
represent empty (0 or 4mA) dependant on P*890 (mA Range) to a level of
15 feet (20mA). If so P*892 (Low Value) should be set to 0.00 feet and
P*893 (High Value) should be set to 15 feet.
P*892 mA2 Low Value
This parameter sets, in Measurement Units (P*104), the value of ‘level’,
‘distance’ or ‘space’, depending on the selected mA Out Mode (P*891) at
which the low mA output will occur (0 or 4mA dependant on (P*890) mA
Range)
Default = 0.000 feet
P*893 mA2 High Value
This parameter sets, in Measurement Units (P*104), the value of ‘level’,
‘distance’ or ‘space’, depending on the selected mA Out Mode (P*891) at
which the high mA output will occur (20mA).
Default = 19.685 feet
Limits
P1 and P2
P*894 mA2 Low Limit
This parameter sets the lowest value that the mA output will drop to, the
default is 0mA, but you can override this if the device you connect to cannot
for example accept less than 2mA, yet you want to use the 0-20mA range.
Default = 0.00mA
P*895 mA2 High Limit
This parameter sets the highest value that the mA output will rise to, the
default is 20 mA, but you can override this if the device you connect to
cannot for example accept more than 18 mA, yet you want to use the 0-20
mA range.
Default = 20.00mA
