P1-882, P2-882 Process Filter
This parameter determines the number of ‘cycles’ that will be taken before a
change in level is processed and the display updated.
level will be updated every cycle
level will be updated every 8 cycles
level will be updated every 16 cycles
P884 Peak Percentage
When P1-102, P2-102 = 2 (Solids), this parameter can be used to determine
the point at which the the measurement is taken, within the established gate
of the selected echo, in order to compensate for any error that maybe caused
by “angles of repose” presented by the way the material settles. Please
consult Pulsar for further information and assistance on changing the value
of this parameter.
Echo Processing Parameters
Transducer 1 Status
P1
P1-900 Transducer 1 Status
This parameter shows the current state of the transducer on Point 1. The
value means the following.
Transducer working correctly.
Transducer is not being used (mA input is being
used instead, so P101=1)
Indicates that the power and signal lines on the
transducer terminals are crossed over, or the signal
line is shorted to earth.
No transducer is detected.
P1-901 Echo Confidence1
This parameter displays the most recent echo confidence from the transducer
on Point 1. It is useful to help find the best mounting location for the
transducer, where you should aim to get the highest figure. It is a percentage
of confidence that the echo reporting the level is the correct one.
