Pulsar ULTRA TWIN User Manual

Page 173
mA Output 2 Parameters
Range
P1 and P2
P*890 mA2 Range
This parameter determines the range of the mA output, from the following.
Option
Description
0= Off
mA output disabled.
1= 0 to 20 mA
mA output directly proportional to the mA mode
(P*891), so if the reading is 0% then the mA output is
0 mA. If the reading is 100% then the mA output is 20
mA.
2= 4 to 20 mA
(Default)
mA output directly proportional to the mA mode
(P*891), so if the reading is 0% then the mA output is
4 mA. If the reading is 100% then the mA output is 20
mA.
3= 20 to 0 mA
mA output inversely proportional to the mA mode
(P*891), so if the reading is 0% then the mA output is
20 mA. If the reading is 100% then the mA output is 0
mA.
4= 20 to 4 mA
mA output inversely proportional to the mA mode
(P*891), so if the reading is 0% then the mA output is
20 mA. If the reading is 100% then the mA output is 4
mA.
