Pulsar ULTRA TWIN User Manual

Page 116
The next parameter will determine which point(s) of measurement that the
alarm relay is to be allocated to.
P*216, P*226, P*236, P*246, P*256, P*266 - Relay Allocation
When P*211, 221, 231, 241, 251, 261 = 1 (Level)
This parameter determines which point(s) of measurement the relay will
react to.
Option
Description
1= Point 1 (Default)
Relay acts on Point 1 calculated levels.
2= Point 2
Relay acts on Point 2 calculated levels.
3= Avg. 1 & 2
Relay acts on calculated average level of 1 & 2.
4= Sum 1 + 2
Relay acts on calculated sum level of 1 & 2.
5= Diff. 1 - 2
Relay acts on calculated differential level of 1 – 2
When P*211, 221, 231, 241, 251, 261 = 2 (Rate of Change), 3
(Temperature) or 4 (Loss of Echo)
Option
Description
1= Point 1 (Default)
Relay acts on Point 1calculated values.
2= Point 2
Relay acts on Point 2 calculated values.
When P*211, 221, 231, 241, 251, 261 = 5 (Loss of Clock), 6 (Device Fail)
or 7 (Device Alarm)
This parameter has no function and will not be displayed.
