The fourth parameter, and fifth parameter, are set to determine the switch
points, “ON” and “OFF” for the relay. See miscellaneous function table
(P*211, 221, 231, 241, 251, 261) for further information.
When P*211, 221, 231, 241, 251, 261 = 1 (Clock)
P*213, P*223, P*233, P*243, P*253, P*263 - Relay Setpoint 1
Relay Setpoints are entered in Hours & Minutes (HH:MM) to set Time at
which relay will energise. Default = 00:00 (HH:MM)
P*214, P*224, P*234, P*244, P*254, P*264 - Relay Setpoint 2
Relay Setpoints are entered in Minutes to set Time Period that the relay will
remain ON. Default = 0.00 mins.
When P*211, 221, 231, 241, 251, 261 = 2 (Totaliser)
P*213, P*223, P*233, P*243, P*253, P*263 - Relay Setpoint 1
Relay Setpoints are entered as a factor by which the on board totaliser
(P1-820/P2-820) should be multiplied by to provide a relay closure.
Default = 0.00
P*214, P*224, P*234, P*244, P*254, P*264 - Relay Setpoint 2
Relay Setpoints are entered in seconds to set the time period that the relay will
remain ‘ON’. Default = 0.00 secs.
P*216, P*226, P*236, P*246, P*256, P*266 - Relay Allocation
When P*211, 221, 231, 241, 251, 261 = 1 (Clock)
This parameter has no function and will not be displayed.
When P*211, 221, 231, 241, 251, 261 = 2 (Totaliser)
This parameter determines which totaliser the relay is assigned to.
