Page 133
Input Function
Individual inputs can be configured for any one of a number of Functions as
determined by P*373, 376, 379, 382, 385, 388, 391 these functions are as
follows:
1 = Device Fail input will provide a signal indicating a “failure” or the
presence of a “run” signal from the device. When
using digital inputs to detect a “run” condition the
input is assumed to be in its operational status until the
expiry of P*304 Input Delay which is used to
determine the delay time that occurs from the time that
the device is called to “run” and the digital input
providing a signal appropriate to its operational status.
2 = Duty input will provide a signal to manually select the lead
device.
3 = Override ON input will provide a signal to override all selected
pump setpoints “ON”.
4 = Override OFF input will provide a signal to override all selected
pump setpoints “OFF”.
5 = Reset input will provide a signal to reset all Device Fail
signals.
6 = Inhibit Meas. Input will provide a signal to inhibit the measurement
of the point it is allocated too.
