Pulsar ULTRA TWIN User Manual

Page 156
Pimary Measuring Device
P1-710
P2-710
Dim A
P1-711
P2-711
Dim B
P1-712
P2-712
Dim C
P1-713
P2-713
Dim D
P1-700, P2-700 = 2 BS 3680 Flume
P1-701, P2-701 = 1 Rectangular
Approach
Width
Throat
Width
Throat
Length
Not
Required
P1-700, P2-700 = 2 BS 3680 Flume
P1-701, P2-701 = 2 Rect. + hump
Approach
Width
Throat
Width
Throat
Length
Hump
Height
P1-700, P2-700 = 2 BS 3680 Flume
P1-701, P2-701 = 3 U-Throated
Approach
Width
Throat
Diameter
Throat
Length
Not
Required
P1-700, P2-700 = 2 BS 3680 Flume
P1-701, P2-701 = 3 U-Throat. + hump
Approach
Width
Throat
Diameter
Throat
Length
Hump
Height
P1-700, P2-700 = 3 BS 3680 Weir
P1-701, P2-701 = 1 Rectangular
Approach
Width
Crest
Width
Crest
Height
Not
Required
P700 = BS3680 Weir
P701 = 3 Rect. Broadcrested
Approach
Width
Crest
Length
Crest
Height
Not
Required
P1-700, P2-700 – 5 Special
P1-701, P2-701 = 1 Palmer-Bowlus
Flume
Size
Not
Required
Not
Required
Not
Required
P1-700, P2-700 – 5 Special
P1-701, P2-701 = 2 H - flume
Flume
Size
Not
Required
Not
Required
Not
Required
P1-700, P2-700 – 5 Special
P1-701, P2-701 = 3 V–Notch angle
V–Notch
angle
Not
Required
Not
Required
Not
Required
