Page 161
P1-804, P2-804 Display Conversion
The reading is multiplied by the value of this parameter before being
displayed. The default is 1.0, but if for example you wanted to display the
reading in yards, then set the Measurement Units (P*104) to feet, and set
P1-804, P2-804 to 3.
P1-805, P2-805 Display Source
This parameter determines which point(s) of measurement the display will
relate to.
Option
Description
1= Point 1
Displays Point 1 calculated values in chosen
Measurement Units.
2= Point 2
Displays Point 2 calculated values in chosen
Measurement Units.
3= Avg. 1 & 2
Displays calculated average values of Point 1 & 2
in chosen Measurement Units.
4= Sum 1 + 2
Displays calculated sum values of Point 1 + 2 in
chosen Measurement Units.
5= Diff. 1 - 2
Displays calculated differential values of Point
1 - 2 in chosen Measurement Units.
Important Information
When the display is to be used to show the value of the average, differential or
sum of two points of measurement, then both points must be set to the same
units of measurement. In the case of flow (P1-100 and P2-100 are set for 4
(OCM Head) or 5 (OCM Flow), then P1-706, P2-706 (Volume Units) & P1-
707, P2-707 (Time Units) must be the same. In case the of Volume then
P1-100 and P2-100 are set for 6 (Volume) then P1- 605, P2-605 (Volume
Units) must be the same.
