Page 49
To program the Ultra Twin for Example 3 Volume Application with
Control by using the Quick Setup menu proceed as follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
At the Quick Setup menu press ENTER and as prompted, by the questions,
select the relevant option and ENTER.
Question
Option
Application
1= Level/Vol.
Level/Volume
2= Volume
Control
1= Control Down
No. of Controls
1 = 1 Relay
Control No. 1
1 = Set Relay 1
No. of Alarms
2 = 2 Alarms
Type Alarm 1
1 = High
Alarm No. 1
4 = Set Relay 4
Type Alarm 2
2 = Low
Alarm No. 2
5 = Set Relay 5
Xducer (P1-101)
2 = dB6
Material (P1-102)
1= Liquid
Measnt Units (P*104)
4 = feet
Empty Level (P1-105)
11.0 (feet)
Span (P106)
10.0 (feet)
Vessel Shape (P1-600)
0 = Cylindrical Flat Base
Vessel Dimensions
Enter Vessel Dimensions as requested
(depends on vessel shape chosen)
Volume Units
Select as required
Max. Volume (Read
Only)
Displays the Max Volume as calculated by
the Ultra Twin
Programming is now complete and the unit can be returned to the run mode,
press CANCEL until Run Mode? Is displayed on the LCD press ENTER,
and the Ultra Twin will return to the Run Mode.
Note
If relay setpoints do not meet the exact requirements of the
application, they can be modified to suit by pressing ENTER when,
“For More Options Hit Enter”, is displayed and entering new values
to relay setpoints as required. Alternatively the relevant relay
setpoint can be accessed either by the main menu system or directly
via parameter number and changed as necessary.
