Page 60
To program the Ultra Twin for Example 1 Sump control (pump down)
using the Quick Setup menu proceed as follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
At the Quick Setup menu press ENTER and as prompted, by the questions,
select the relevant option and ENTER.
Question
Option
Application
2 = Pump
Level, Pump Up/Down
2 = Pump Down
No. of Pumps
2 = 2 Pumps
Pump Duty
3 = Alt DutAss
Pump No. 1
1 = Set to Relay 1
Pump No. 2
2 = Set to Relay 2
No. of Alarms
1 = 1 Alarm
Type Alarm 1
1 = High
Alarm No.1
5 = Set to Relay 5
Xducer (P1-101)
2 = dB6
Measnt Units (P*104)
4 = feet
Empty Level (P1-105)
11.0 (feet)
Span (P1-106)
10.0 (feet)
Programming is now complete and the unit can be returned to the run mode,
press CANCEL until Run Mode? Is displayed on the LCD press ENTER,
and the Ultra Twin will return to the Run Mode.
Note
If relay setpoints do not meet the exact requirements of the
application, they can be modified to suit by pressing ENTER when,
“For More Options Hit Enter”, is displayed , and entering new
values to relay setpoints as required. Alternatively the relevant relay
setpoint can be accessed either by the main menu system or directly
via parameter number and changed as necessary.
