Pulsar ULTRA TWIN User Manual

Page 80
To program the Ultra Twin for Example 2 BS3680 U-Throated Flume by
using the Quick Setup menu proceed as follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
At the Quick Setup menu press the hot key and toggle to Point 2 display
and press ENTER and then as prompted, by the questions, select the
relevant option and ENTER.
Question
Option
Application
3 = Flow
PMD Type
2 = 3680 Flume
3680 Flumes
3 = U Throat
Calculation
1 = Absolute
No. of Alarms
1 = 1 Alarm
Type Alarm 1
2 = Low
Alarm No 1
1 = Set Relay 1
Xducer (P2-101)
1 = dB Mach3
Volume Units (P2-706)
6 = Mil. USG
Time Units (P2-707)
3 = Per Hour
Measnt. Units (P*104)
5 = inches
Empty Level (P2-105)
35.0 inches
Minimum Head (P2-703)
0.000 inches
Maximum Head (P2-704)
15 inches
Total Alloc. (P2-824)
1 = Point 1
Aux. Mode (P2-815)
7 = Totaliser (R)
Aux. Source (P2-816)
1 = Point 1
Total Multiplier (P2-823)
4 = *1
Approach. Dia.(P2-710)
28.0 inches
Throat Dia. (P2-711)
20.0 inches
Throat Len. (P2-712)
40.0 inches
Programming is now complete and the unit can now be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Ultra Twin will return to Run Mode.
Note
If relay setpoints do not meet the exact requirements of the
application, they can be modified to suit by pressing ENTER when,
“For More Options Hit Enter”, is displayed, and entering new
values to relay setpoints as required. Alternatively the relevant
relay setpoint can be accessed either by the main menu system or
directly via parameter number and changed as necessary.
