Pulsar ULTRA TWIN User Manual

Page 84
To program the Ultra Twin for Example 3 BS3680 Weir by using the
Quick Setup menu proceed as follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
At the Quick Setup menu press ENTER and as prompted, by the questions,
select the relevant option and ENTER.
Question
Option
Application
3 = Flow
PMD Type
3 = 3680 Weir
3680 Flumes
1 = Rectangular
Calculation
1 = Absolute
No. of Alarms
1 = 1 Alarm
Type Alarm 1
1 = High
Alarm No 1
3 = Set Relay 3
Xducer
1 = dB Mach3
Volume Units
5 = US gallons
Time Units
2 = Per Minute
Measnt. Units
5 = inches
Empty Level
40.0 inches
Minimum Head
0.000 inches
Maximum Head
16.0 inches
Total Alloc.
1 = Point 1
Aux. Mode
7 = Totaliser
Aux Source
1 =Point 1
Total Multiplier
7 = *1000
App. Width (Dim A)
18.0 inches
Crest Width (Dim B)
12.0 inches
Crest Height (Dim C)
10.0 inches
Programming is now complete and the unit can now be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Ultra Twin will return to Run Mode.
Note
If relay setpoints do not meet the exact requirements of the
application, they can be modified to suit by pressing ENTER when,
“For More Options Hit Enter”, is displayed , and entering new
values to relay setpoints as required. Alternatively the relevant relay
setpoint can be accessed either by the main menu system or directly
via parameter number and changed as necessary.
