Qirod QD100 Series - Description of Alarm and Indication Code; Alarm Display and Measures

109
stop fault keyboard panel
to perform stop
operation when
the motor works
under remote
mode.
e-45
Torque
boost is
too large

Setting of
torque boost
parameter f203
is too high.

Motor
impedance is
too low.

Repeat self-tuning of
the inverter and
downward tune
parameter f203.
e-46
Self-setting
error

Confirm
whether motor
rated parameter
settings are
correct.

The motor
capacity is far
smaller than that
of the inverter.

Cable of the
motor is too thin.

Motor is still in
rotation when
the self-setting
starts.

Correctly set motor
rated parameters.

Use inverter with
larger capacity.

Apply thicker cable of
the motor.

Confirm the motor
has stopped before the
self-setting begins.
Description of alarm and indication code
Table 3.2 Alarm display and measures
Code
Description
Cause Measures
