7
Here the display data type can be set freely under the Powering-on default
mode,showed in the parameter F610
Parameter Setting Mode
There are 10 groups function parameters from f0 group to f9 group,each group includes
different numbers function parameter. The Parameter setting value can be modified by
▲or▼key and ENT key, or give up the modification by ESC key, as showed as Figure
1.4
Figure 1.4 Parameter Setting Mode navigation
Status monitoring mode
The status monitoring mode can be used to monitor the current running status of inverter,
or check the fault record, the operation shows as the Figure 1.5
20.0
