Note 2: The difference between 2-wire control and 3-wire operation configuration lies in
whether logic input function 30 (3-wire control shutdown input) is used.
NO. Parameter Name Setting Range
Default
f305 AI1 voltage-current input selection 0~2 0
1:05V voltage signal input.
2:010V voltage signal input.
Note: AI2 only accept 0~10VDC voltage signal input, setting value of f305 will not change
the characteristic of AI2.
NO. Parameter Name Setting Range Default
f306 sink/source mode selection 0~1 1
0: Source (Positive) logic terminal mode.
1: Sink (Negative) logic terminal mode
NO. Parameter Name Setting Range Default
f307 AO voltage-current output selection
0~1 1
0: Current signal output.
1: Voltage signal output.
NO. Parameter Name Setting Range Default
f308 Input terminal function of AI1 0~69 0
When f300 disabled, the set value of f308 cannot be read out.
When f300 set at 1or 2, AI1 is enabled, and can be used as a contact input terminal.
NO. Parameter Name Setting Range
Default
f309 Always-active terminal selection 1 0~69 1
f310 Always-active terminal selection 2 0~69 0
f309 and f310 specifies an input terminal function that is always to be kept active (ON).
