40
60
Reserve running
command + multisection
velocity 4+ acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, reserve running command and the
multisection velocity 4
61
UP/DOWN speed clear +
fault reset
From OFF to ON, clear the frequency level
of the UP/DOWN input set
62
Operation license +
forward running command
(only 2-wire control)
ON: Simultaneously activate operation
license, forward running command
63
Operation license +
reserve running
command (only 2-wire
control)
ON: Simultaneously activate operation
license, reserve running command
64
Acceleration/deceleration
curve 3
ON: The motor accelerates according to
acceleration curve 3
65
Acceleration/deceleration
curve 3 + forward running
command
ON: Simultaneously activate forward
running, Acceleration/deceleration curve 3
command
66
Acceleration/deceleration
curve 3 + reserve running
command
ON: Simultaneously activate reserve
running, Acceleration/deceleration curve 3
command
67 Command source switch
OFF: Command source according to F002
ON: Command source according to F004
68
Command source + frequ
ency source switch
OFF: Command source according to F002,
frequency source according to F003
ON: Command source according to F004,
frequency source according to F005
69
3-wire control stop
counter
OFF: inverter is ready to sun
ON: From ramp slow down to stop
70 Simple PLC stop reset
ON: Clear PLC state memory information,
re-start simple PLC process
71 Simple PLC pause
ON: Operation as current speed; after
revocation, PLC continues to run
Note1: AI1 and AI2 could be used as contact input terminals (see f300, f308, f313 and
f314).
