73
Figure 2.29 S-pattern acceleration/deceleration 2
NO. Parameter Name Setting Range
Default
f511 Acceleration/deceleration 2 pattern
0~2 0
f512 Acceleration/deceleration 3 pattern
0~2 0
0: Linear, This pattern can usually be used.
1: S-pattern 1.
2: S-pattern 2.
NO. Parameter Name Setting Range Default
f513
Acceleration/deceleration 1 and 2
switching frequency
0.0 Hz ~f008 0.0
f514
Acceleration/deceleration 2 and 3
switching frequency
0.0 Hz ~f008 0.0
