Qirod QD100 Series User Manual

46
OFF Motor is not in acceleration state
60
ON Motor is in acceleration state
OFF Motor is not in deceleration state
62
ON Motor is in deceleration state
OFF Motor is not in acceleration or deceleration state
64
ON Motor is in acceleration or deceleration state
OFF
Radiator temperature does not reach the alarm
threshold
66
ON Radiator temperature reaches the alarm threshold
OFF PLC is in the process of cycling
68
ON
After one PLC cycling is completed, output one ON
pulse
OFF Running at a certain PLC section speed
70
ON
After one PLC section is completed, output one ON
pulse
OFF Not used
75~253
ON Not used
254 OFF Output always OFF
255 ON Output always ON
Note 1: Inversion logic can be obtained by add 1 to the output terminal function number.
Example: f315=3 is the inverter logic action of f315=2.
Note 2: Output terminal function is available for LO-CLO(f311、f312)和 T1, T2 (f315、
f359、f360).
NO. Parameter Name Setting Range
Default
f316 Output terminal logic selection of LO-CLO
0~1 0
0: f311 AND f312. The logical product (AND) of f311 and f312 will be output to LO-CLO.
1: f311 OR f312. The logical sum (OR) of f311 and f312 will be output to LO-CLO.
NO. Parameter Name Setting Range Default
f317 LO-CLO output delay 0~60.0 s 0.0
f317 specified the time of LO-CLO output delay.
