45
OFF The output current is equal to or larger than f408+f409
34
ON
The output current is equal to or less than f408 for
f410 set time
OFF When inverter is not significant trip
36
ON When inverter is significant trip
OFF When inverter is not insignificant trip
38
ON When inverter is insignificant trip
OFF
When inverter does not trip or retry
40
ON When inverter trips or retries
OFF alarm off
42
ON alarm on
OFF
calculated value of motor overload level < 50%
44
ON
calculated value of motor overload level ≥ 50%
OFF
calculated value of brake resister overload level < 50%
46
ON
calculated value of brake resister overload level ≥ 50%
OFF Torque current <
（
f412*70% - f413
）
48
ON Torque current ≥ f412*70%
OFF Cumulative operation time
＜
f428 setting
50
ON Cumulative operation time ≥f428 setting
OFF
Calculation for parts replacement time is shorter than
the preset time (internally preset)
52
ON
Calculation for parts replacement time is equal to or
longer than the preset time (internally preset)
OFF Normal condition
54
ON PTC detected value ≥ 60% of protection level
Output
terminal
function NO.
Output
Status
Description
OFF Other than undervoltage detected
56
ON Undervoltage detected
OFF Mechanical brake release
58
ON Mechanical brake not release
