Qirod QD100 Series User Manual

123
Bit
Description of
function
0 1
Default
value
11 Multi-speed 4 OFF ON 0
12
Motor parameter
switch
1nd Motor
Parameter
2nd Motor
Parameter
0
13 PID control Disabling
Enabling PID
control
Disabling PID
control
0
14
Acceleration/
deceleration curve
switch
Acceleration/
deceleration
curve 1
Acceleration/
deceleration
curve 2
0
15 DC braking No DC braking DC braking start
0
3) Communication running frequency setting (Communication address: FA08)
Table A.11 Communication running frequency setting
Bit Description of function Default
0-15
Running frequency data of communication setting. Hexadecimal
setting: 50Hz(50Hz)x100 = 50001388Hz
It is if setting: 50Hz, write 1388H in the fa08 address
0.0
4) Communication analog output setting (Communication address: fa16)
Table A.12 Communication analog output setting
Bit
Description of function Lower limit
Upper limit
Default
0-15
Analog output data of communication
setting (in correspondence with analog
output function 10)
0
（0000H
）
1023
（03FFH
）
0
2. Monitoring parameter
Read monitoring parameter through serial communication in order to view the running
state of the inverter. The following table provides part of monitoring parameters. See
“5.11 Monitoring function parameter group” for other parts.
Table A.13 Communication running frequency setting
No.
Communicati
on address
Description of function Unit Note
1
FD03 Real-time running state -
See table A.14
for details
