Qirod QD100 Series User Manual

100
Note 2: You can switch between % and A (ampere)/V (volt), using the parameter f604
(current/voltage unit selection).
Note 3: The input/output voltage displayed is as large as the AC root-mean-square input.
Note 4: The integrated amounts of input and output power will be reset to zero, if you
press and hold down the ENT key for 3 seconds or more when power is off or when the
input terminal function 32 is turned on or displayed.
Note 5: The cumulative operation time increments only when the machine is in operation.
Note 6: At the occurrence of a trip, maximum values are not always recorded and
displayed for reasons of detecting time.
Table 2.13 Display of detailed information on past trip n (n=1,2,3,4)
NO.
Parameter
Name
Description
- Cause of trip E.g. e-01
un00 Continuous trips
The number of time the same trip occurred in succession
is displayed. (Unit: times)
un01 CPU1 Version
E.g: , G-type, v= g; P-type, v= p
；
un02
Operation
frequency
Value is displayed in Hz/free unit. See f604.
un03
Direction of
rotation
Forward run, Reverse run.
un04
frequency
command value
Value is displayed in Hz/free unit. See f604.
un05 load current The inverter output current (%/A) is displayed.
un06
input voltage
(AC RMS)
The inverter input voltage (200/V) is displayed.
un07
output voltage
(AC RMS)
The inverter output voltage command (200/V) is
displayed.
un08
Input terminal
status indicated
NO.
Parameter
Description
v
100
0
1
：
OFF
：
ON
<
}
<>
i
}
2
AI
1
-
AI
L
I
2
L
I
3
L
I
1
4
L
I
5
L
I
