Qirod QD100 Series User Manual

124
No.
Communicati
on address
Description of function Unit Note
2 FD12 Real-time running frequency 0.01 Hz
3 FE18 Actual output frequency 0.01 Hz
4 FE09 DC bus input voltage 0.01 %
5 FE10 Output voltage 0.01 %
6 FE08 Output current 0.01 %
7 FE20 Output torque 0.01 %
8 FE29 Output power 0.01 kW
9 FE50 Motor speed (estimated) 1 rpm
10
FE11 Logic input -
See A.15 for
details
11
FE12 Logic output -
See A.16 for
details
12
FE30
Logic input AI1 (10-bit
accuracy)
-
Range (0-
1023)
13
FE31
Logic input AI2 (10-bit
accuracy)
-
Range (0-
1023)
14
FC39 Fault monitoring -
See A.17 for
details
Table A.14 Real-time running state monitoring
Communication
address
Description of function
FD03 Real-time running state monitoring
Bit Description 0 1
0 Reserved - -
1 Fault No fault Tripping
2-8 Reserved - -
9 Forward/reverse rotation
Forward
rotation
Reverse
rotation
10 Running/stop Stop Running
11-15 Reserved - -
