Qirod QD100 Series User Manual

76
input terminal function
64
input terminal function
5
Acc/Dec selection
0 0 Acc/Dec1
0 1 Acc/Dec 2
1 0 Acc/Dec 3
1 1 Acc/Dec 3
Table 2.9 Using input contact terminal and switching frequency select Acc/Dec
Frequency command
input terminal
function 5
input terminal
function 64
Acc/Dec selection
0 0 ACC1
1 0 ACC2
0 1 ACC1
Fc =< f513
1 1 ACC2
0 0 ACC2
1 0 ACC1
0 1 ACC2
f513 < Fc =< f514
1 1 ACC1
0 0 ACC3
1 0 ACC3
0 1 ACC3
f514 < Fc
1 1 ACC3
Note: (A) and (F) according to Acc/Dec 1；(B) and (E) according to Acc/Dec 2；(C) and
(D) according to Acc/Dec 3.
NO. Parameter Name Setting Range
Default
f522 Reverse-run prohibition 0~2 0
0: Forward/reverse run permitted.
1: Reverse run prohibited.
2: Forward run prohibited.
