44
OFF Output frequency ≤ f338-f339
10
ON Output frequency ≥f338+f339
OFF Frequency commanded by f003or f005 ≠AI1 value
12
ON Frequency commanded by f003or f005= AI1 value
OFF Frequency commanded by f003or f005 ≠AI2 value
14
ON Frequency commanded by f003or f005= AI2 value
OFF AI1 value≤f340-f341
16
ON AI1 value ≥f340+f341
OFF AI2 value ≤f342-f343
18
ON AI2 value ≥f342+f343
OFF
Terminal other than AI2 selected as frequency
command
20
ON AI2 selected as frequency command
OFF Operation stopped
22
ON When operation frequency is output or during (A-07)
OFF Not for ready for operation
24
ON
Ready for operation (Input function of standby and run
are not ON)
OFF forward run
26
ON reverse run
OFF remote control mode
28
ON local control mode
OFF When inverter is not tripped
30
ON When inverter is tripped or retries.
Output
terminal
function NO.
Output
Status
Description
OFF Torque current is equal to or less than f412 - f413
32
ON
Torque current is equal to or larger than f412 set value
and longer than f414 set time.
