Qirod QD100 Series User Manual

39
51
Multisection velocity 3
+ acceleration decelerati
on curve 2
ON: Simultaneously activate acceleration
curve 2, the multisection velocity 3
52
Multisection velocity 4
+ acceleration decelerati
on curve 2
ON: Simultaneously activate acceleration
curve 2, the multisection velocity 4
53
Forward running
command + multisection v
elocity 1 + acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, forward running command and the
multisection velocity 1
54
Reserve running
command + multisection
velocity 1 + acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, reserve running command and the
multisection velocity 1
55
Forward running
command + multisection
velocity 2 + acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, forward running command and the
multisection velocity 2
56
Reserve running
Command + multisection
velocity 2 + acceleration
deceleration curve 2
ON:Simultaneously activate acceleration
curve 2, reserve running command and the
multisection velocity 2
57
Forward running
command + multisection
velocity 3 + acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, forward running command and the
multisection velocity 3
58
Reserve running
command + multisection
velocity 3 + acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, reserve running command and the
multisection velocity 3
59
Forward running
command + multisection
velocity 4+ acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, forward running command and the
multisection velocity 4
Input
terminal
function
NO.
Function name Description
