38
40
Reverse running
Command + acceleration
deceleration curve 2
ON: The motor runs reverse, slope
acceleration according to acceleration
deceleration curve 2
41
Forward running
Command + multisection
velocity 1
ON: The motor runs forward, at the same
time to activate the multisession velocity 1
42
Reserve running
Command + multisection
velocity 1
ON: The motor runs reserve, at the same
time to activate the multisection velocity 1
43
Forward running
Command + multisection
velocity 2
ON: The motor runs forward, at the same
time to activate the multisection velocity 2
44
Reserve running
Command + multisection
velocity 2
ON: The motor runs reserve, at the same
time to activate the multisection velocity 2
45
Forward running
Command + multisection
velocity 3
ON: The motor runs forward, at the same
time to activate the multisection velocity 3
46
Reserve running
Command + multisection
velocity 3
ON: The motor runs reserve, at the same
time to activate the multisection velocity 3
47
Forward running
Command + multisection
velocity 4
ON: The motor runs forward, at the same
time to activate the multisection velocity 4
48
Reserve running comman
d
+ multisection velocity 4
ON: The motor runs reserve, at the same
time to activate the multisection velocity 4
49
Multisection velocity 1
+acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, the multisection velocity 1
50
Multisection velocity 2
+ acceleration
deceleration curve 2
ON: Simultaneously activate acceleration
curve 2, the multisection velocity 2
Input
terminal
function
NO.
Function name Description
