37
NO.
28
inversion of thermal trip
stop signal input from
external device
OFF: e-25 Trip stop
ON: No outer over-heat fault
29
Forced switching from
remote to local control
Enabled when remote control is exercised
ON: Local control (setting of cmod, f002
、
f003
和
f005)
OFF: Remote control
30
Operation holding (stop of
3-wire operation)
ON: forward /reverse run held, 3-wire
operation
OFF: Slowdown stop
31
Forced switching of
command mode and
terminal board command
ON: Terminal board operation
OFF: Setting of f002
32
Display cancellation of the
cumulative power amount
(kWh)
ON: Monitor display cancellation of the
cumulative power amount (kWh)
33
Fire-speed control
seef419
ON: Fire-speed operation (preset speed
operation
frequency f730)
OFF: Normal operation
34 Coast stop (gate off)
OFF: Motor is ready for running
ON: Coast stop (gate off)
35 Inversion of Reset
ON: Acceptance of reset command
OFF→ ON: Trip reset
36
Forced switching of stall
prevention level 2
ON: Enabled at the value of f111
OFF: Enabled at the value of f107
37
PID control integral value
clear PID control integral
value clear
ON: PID control integral value always zero
OFF: PID control permitted
38
inversion of PID error
signal
ON: PI error input = feedback – setting
OFF: PI error input = setting – feedback
39
Forward running
command
+ acceleration
deceleration curve 2
ON: The motor runs forward, slope
acceleration according to acceleration
deceleration curve 2
Input
terminal
function
NO.
Function name Description
