f300
AI1
terminal
function
selection
0: AI1 - analog input
1: AI1 - contact input (Sink
mode)
2: AI1 - contact input
(Source mode)
0 ●
f301
Input
terminal
function for
LI1
2 ●
f302
Input
terminal
function for
LI2
3 ●
f303
Input
terminal
function for
LI3
0 ●
f304
Input
terminal
function for
LI4
0:No function is assigned
1:Standby terminal
2:Forward run command
3:Reverse run command
4:Jog run mode
5:Acceleration/deceleration 2
pattern selection
6:Preset-speed command 1
7:Preset-speed command 2
8:Preset-speed command 3
9:Preset-speed command 4
10:Reset command
11:Trip stop command from
external input device
13:DC braking command
14:PID control disabling
15:Permission of
parameter editing
16:Combination of standby
and reset commands
17:Frequency source
switching to AI1
18:Combination of forward
run and jog run
19:Combination of reverse
run and jog run
20:Frequency setting source
switching
21:No.2 Switching of V/F
setting
22:No.2 motor switching
10 ●
