Qirod QD100 Series User Manual

5
No.
Item Symbol
Function
% On – Unit of the displayed number is percentage
3
UNIT
indication
lamp
Hz On – unit of the displayed number is Hz
REV Direction of rotation Indication
LOC Local or remote indication
4
State
indication
lamp
ALM Fault indication
5 MODE key
MODE
To select keyboard display mode or return to
MODE from sub menu
6
UP key ▲
To increase parameter number or parameter set
value
7
ESCAPE
key
ESC
To return to the previous state before the pressing
of the ENT key
8
DOWN
key
▼
To reduce parameter number or parameter set
value
9
ENTER
key
ENT
Press the key to display or confirm different
modes, parameters or set values
10
STOP/RE
SET key
STOP/
RESET
Press the key to stop the frequency inverter. The
key becomes a RESET key when fault is
discovered
11
JOG key JOG
Press this key to enter into jog (inching) function
under the invert’s start model
12
RUN key RUN To run the inverter
13
Speed
control
knob
-------
To adjust speed
