Qlogic QConvergeConsole CLI 2400 Series User Manual

8–NIC Interactive Commands
NIC Port Setting Configuration
8-8 SN0054667-00 C
Display Configured Port Settings (-iset)
2. Adapter Configuration1. CNA Configuration2. NIC Port Setting Configuration<port selection>
1. Display Configured Port Settings
From the Port Settings Menu, select the Display Configured Port Settings
option to view the configure port parameters. For example:
IPv4_Checksum_Offload_Enable : RxTx
Jumbo_Frames_MTU_9000_Enable : off
LOCAL_Administered_Address_MAC : 00:0e:1e:04:d3:34
Port_Alias : None
Port_Wake_On_LAN_Option : Disabled
Port_PXE_Enable : off
Flow_Control : Rx Tx Enabled
Max_Jumbo_Buffers : 1024
Receive_Buffer_Count : 4096
Transmit_Buffer_Count : 1024
Configure Port Settings
2. Adapter Configuration1. CNA Configuration2. NIC Port Setting Configuration<port selection>
2. Configure Port Settings
From the Port Settings Menu, select the Configure Port Settings option to
configure port parameters. For example:
IPv4_Checksum_Offload_Enable (off, Rx, Tx, RxTx)[RxTx]:
Jumbo_Frames_MTU_9000_Enable (on, off)[off]:
WOL available options:
0 = Disabled,
1 = Wake on Magic Frame,
Port_Wake_On_LAN_Option [Disabled]:
Port_PXE_Enable (on, off)[off]:
Flow_Control (Rx, RxTx)[Rx Tx Enabled]:
Max_Jumbo_Buffers (128, 256, 512, 1024)[1024]:
Receive_Buffer_Size (1024, 2048, 4096, 8192)[4096]:
Transmit_Buffer_Size (128, 256, 512, 1024)[1024]:
Change Port Alias Name (-n)
2. Adapter Configuration1. CNA Configuration2. NIC Port Setting Configuration<port selection>
3. Change Port Alias Name
From the Port Settings Menu, select the Change Port Alias Name option to
change the port alias. For example:
Port_Alias [None]: port_alias
Successfully saved Port Alias
