RADWIN2000CPlusUserManual Release3.5.70 13‐6
ConfigurationofVLANTaggingforEthernetService Chapter13
3.EnteraProviderVLANIDandPriority.TheVLANIDmustbeintherange2to4094.
TheVLANPrioritymustbeintherange0to7.YoumayalsochangetheTPIDfrom
thedefaultasshown.
4.ClickOKtoaccept.
5.ForuserVLANtagging,clicktheTagRadiobutton:
InTagmodeEthernetframesaretaggedoruntaggedtodistinguishbetweendiffer‐
entnetworks.
6.Forcompletelytransparentpassageoftaggedframes,thereisnothingfurthertodo.
ThefollowingtableshowsthepossiblesettingsforeachcombinationofIngressand
Egressmodes:
Note
Thisfacilityisprovidedtoenableconnectionthroughlegacyswitches
requiringit.Otherwise,thereisnoneedtochangetheTPID.
