Rain Bird Maxicom2 User Manual

• Chapter Ten: Viewing Maxicom
2
’s Communication Status
Tells you how to view the status of all Maxicom
2
ports simultaneously, how to
view a single port in detail, and how to disconnect a port from a field device.
• Chapter Eleven: Backing Up Data
Explains how Maxicom
2
backs up your data.
• Chapter Twelve: Glossary
Provides you with a handy glossary of terms.
Terminology Used in this Manual
The following computer-usage terminology is used in this manual:
• Click means to place the cursor on an on-screen item and press the left
mouse button.
• Double-click means to place the cursor on an on-screen item and quickly
press the left mouse button twice.
• Right-click means to place the cursor on an on-screen item and press the
right mouse button.
• Select means to place the cursor in a text field or on a menu option,
checkbox, or radio button and press the left mouse button.
• Check means to click a checkbox so that a check mark appears in the
checkbox.
• Enter means to type text. (If you are required to press the Enter key on the
keyboard, the instructions will say, “Press the Enter key.”)
• Highlight means to place the cursor on an item and press the left mouse
button so that the item’s background is displayed in a different color than the
background of unselected items.
• Drag means to click on an item and hold the mouse button down while you
drag the mouse (and the item) to the desired position on the screen.
• Keyboard accelerators such as “Alt-S” mean to hold down the Alt key and
type an “S.”
Introduction
xiii
For a list of other terms used
in this manual, see the
Glossary on page 12.1.
Saving your work in
Maxicom
2
is an automatic
process that is different from
other Windows applications.
For more information, see
“Saving Your Work” on page
2.35.
